Streaming LangGraph state updates to the browser in real time

AK
Ahad KhanAI Engineer
July 15, 2026
3 min read
LangGraphFastAPISSEPython
Streaming LangGraph state updates to the browser in real timeClick to expand

A multi-agent LangGraph workflow ran for 38 seconds. The user stared at a static loading spinner. Thinking the app had crashed, they hit refresh, killing the execution mid-way and leaving an orphaned state checkpoint in PostgreSQL.

This UX failure happens when agent backends treat long-running workflows as synchronous HTTP request/response cycles.

WebSockets are the typical reflex, but bidirectional socket infrastructure introduces heartbeats, reconnection state management, and firewall proxy issues. Server-Sent Events (SSE) provide a simpler alternative: a unidirectional, HTTP-native stream supported natively in every browser via the EventSource API.

Here is how to stream real-time LangGraph state updates to a browser UI using FastAPI async generators.

Why WebSockets Are Overkill for Agent Telemetry

When an agent graph executes, telemetry flows in one direction: from server to client. The browser does not need to push continuous socket messages back to the server while a node is running.

FeatureServer-Sent Events (SSE)WebSockets
ProtocolStandard HTTP (text/event-stream)WS / WSS protocol upgrade
DirectionServer-to-client (Unidirectional)Bidirectional
Auto-ReconnectBuilt-in native browser supportCustom JS handling required
Proxy / FirewallWorks out of the box on port 80/443Frequently blocked by corporate proxies
Implementation~30 lines of standard PythonRequires dedicated socket server

For agent execution feeds, SSE delivers lower infrastructure overhead and cleaner code.

FastAPI Async Generator Implementation

FastAPI supports SSE via StreamingResponse. We wrap LangGraph's .astream_events() method in an async generator that yields formatted data streams.

python
1import json
2import asyncio
3from fastapi import FastAPI, HTTPException
4from fastapi.responses import StreamingResponse
5from langchain_core.messages import HumanMessage
6from my_agent_graph import graph  # Compiled LangGraph StateGraph instance
7

8app = FastAPI()
9

10async def event_generator(query: str, thread_id: str):
11    """
12    Executes a LangGraph workflow and streams state node execution events to the client.
13    """
14    config = {"configurable": {"thread_id": thread_id}}
15    initial_input = {"messages": [HumanMessage(content=query)]}
16

17    try:
18        # Stream events from LangGraph v0.2+ execution graph
19        async for event in graph.astream_events(initial_input, config=config, version="v2"):
20            event_kind = event["event"]
21            node_name = event.get("name", "graph")
22

23            # Filter for specific events to avoid streaming internal verbose noise
24            if event_kind == "on_chain_start" and node_name != "LangGraph":
25                payload = {
26                    "type": "NODE_START",
27                    "node": node_name,
28                    "timestamp": asyncio.get_event_loop().time()
29                }
30                yield f"data: {json.dumps(payload)}\n\n"
31

32            elif event_kind == "on_chain_end" and node_name != "LangGraph":
33                # Extract output state diff if present
34                output_data = event.get("data", {}).get("output", {})
35                payload = {
36                    "type": "NODE_END",
37                    "node": node_name,
38                    "summary": str(output_data)[:200]  # Truncate summary payload
39                }
40                yield f"data: {json.dumps(payload)}\n\n"
41

42            elif event_kind == "on_chat_model_stream":
43                # Stream individual token deltas as the LLM generates
44                chunk = event["data"]["chunk"].content
45                if chunk:
46                    payload = {"type": "TOKEN_DELTA", "content": chunk}
47                    yield f"data: {json.dumps(payload)}\n\n"
48

49        # Signal completion
50        yield f"data: {json.dumps({'type': 'COMPLETE'})}\n\n"
51

52    except Exception as e:
53        error_payload = {"type": "ERROR", "message": str(e)}
54        yield f"data: {json.dumps(error_payload)}\n\n"
55

56@app.get("/api/agent/stream")
57async def stream_agent_execution(query: str, thread_id: str):
58    return StreamingResponse(
59        event_generator(query, thread_id),
60        media_type="text/event-stream",
61        headers={
62            "Cache-Control": "no-cache",
63            "Connection": "keep-alive",
64            "X-Accel-Buffering": "no"  # Prevents Nginx response buffering
65        }
66    )

Consuming the SSE Stream in JavaScript

The browser's native EventSource API handles stream consumption and automatic reconnection:

javascript
1function connectAgentStream(query, threadId) {
2  const url = `/api/agent/stream?query=${encodeURIComponent(query)}&thread_id=${threadId}`;
3  const eventSource = new EventSource(url);
4

5  eventSource.onmessage = (event) => {
6    const data = JSON.parse(event.data);
7

8    switch (data.type) {
9      case "NODE_START":
10        console.log(`[Executing Node]: ${data.node}`);
11        updateTimelineUI(data.node, "running");
12        break;
13

14      case "NODE_END":
15        console.log(`[Completed Node]: ${data.node}`);
16        updateTimelineUI(data.node, "completed");
17        break;
18

19      case "TOKEN_DELTA":
20        appendLLMTokenToUI(data.content);
21        break;
22

23      case "COMPLETE":
24        console.log("Agent execution finished cleanly.");
25        eventSource.close();
26        break;
27

28      case "ERROR":
29        console.error("Stream error:", data.message);
30        eventSource.close();
31        break;
32    }
33  };
34

35  eventSource.onerror = (err) => {
36    console.error("EventSource failed:", err);
37    eventSource.close();
38  };
39}

Key Engineering Takeaways

  1. Emit State Diffs, Not Full State: If your LangGraph state contains large arrays or retrieved document chunks, emitting full state on every node event will saturate network bandwidth. Stream light event signals (NODE_START, NODE_END, TOKEN_DELTA) and let the UI fetch final detailed state from the checkpoint store.
  2. Disable Reverse Proxy Buffering: Nginx and Cloudflare buffer HTTP responses by default. Setting "X-Accel-Buffering": "no" in HTTP headers ensures proxies flush events to the browser immediately.
  3. Use Thread Checkpoints for Re-hydration: If a browser connection drops mid-execution, PostgresSaver in LangGraph maintains state. When the user reconnects, fetch current state via graph.get_state(config) and resume streaming uninterrupted progress.

This architecture is used in our IT Access Provisioning Automation case study to provide real-time visibility into multi-node agent triage.
